Description
POLYESTER ADHESIVE TAPE 1MIL X 50 MM X 65 MTR
Coil Insulation Polyester Tape 1 MIL X 50 MM X 65 MTR for Melting and Heating Furnace
Polyester Adhesive Tape is a pressure-sensitive electrical insulation tape designed for industrial wrapping, insulation, bundling and protection applications. Polyester film provides good mechanical strength, dimensional stability and electrical insulation, while the adhesive layer provides secure bonding to suitable surfaces.
Available Product Variants
| Product | Thickness | Width | Roll Length |
|---|---|---|---|
| Polyester Tape – 3 MIL | 3 MIL (approx. 0.076 mm) | 20 mm | 50 m |
| Polyester Tape – 1 MIL | 1 MIL (approx. 0.025 mm) | 50 mm | 65 m |
Key Features
Polyester film-based adhesive tape for electrical and industrial applications.
Good dielectric insulation and mechanical strength.
Flexible and suitable for controlled wrapping around components and conductors.
Good adhesion to clean, dry metal and other compatible surfaces.
Available in narrow 20 mm and wider 50 mm formats for different wrapping requirements.
Suitable for OEM, maintenance and replacement applications.
Applications
Induction furnace coil insulation and electrical wrapping applications.
Insulation and protection of electrical connections and components.
Wrapping of wires, cables and electrical assemblies.
Transformer, motor and generator insulation-related applications where the selected tape grade is suitable.
General industrial electrical insulation and component bundling.
Technical Reference Properties
The uploaded reference datasheet identifies F360-YL as a Polyester Adhesive Tape tested to IS 7809 Part II. The following values are reproduced as reference performance data from that datasheet and should not be interpreted as certified values for both EPE tape variants unless the supplied material is confirmed to the same grade.
| Property | Reference Value | Unit / Method |
|---|---|---|
| Temperature Class | 130 | °C |
| Total Thickness | 0.110 ± 10% | mm |
| Tensile Strength – Machine Direction | 8 minimum | kg/cm |
| Elongation at Break – Machine Direction | 60 minimum | % |
| Adhesion to Steel | 220 minimum | g/cm |
| Breakdown Voltage | 7.5 minimum | kV; IS 2584 method |
| Heat Curing | 30 min @ 130°C | Condition |
| RoHS Compliance | Yes | RoHS 2011/65/EU & 2015/863 |
Supply & Identification
| Product Type | Polyester Adhesive Tape |
|---|---|
| 3 MIL Size | 3 MIL × 20 mm × 50 m |
| 1 MIL Size | 1 MIL × 50 mm × 65 m |
| Form | Roll |
| Application | Electrical insulation, wrapping and industrial protection |
🔧 Suitable For
Suitable for induction furnace coil manufacturing and repair in systems supplied by Electrotherm, Inductotherm Group India, and other OEMs.
- Manufacturer names are mentioned solely to indicate typical applications and compatibility.
